DISINFECTION UNIT USING ULTRAVIOLET RADIATION

[Category : - HEALTH- Life-saving; Fire-fighting]
[Viewed 447 times]

The invention relates to a disinfection unit for sterilizing a volume of gas by fragmenting it into segments, physically isolating each segment from the other segments, exposing each segment to UV-C radiation in order to disinfect it, then freeing each segment thus exposed. All the operations of this germicidal filter are sequential and in pipeline mode in order to ensure a continuous gas flow at the outlet. The disinfection unit thus comprises a housing divided into four cells (156a-d), each having a first orifice and a second orifice, where each cell is equipped with a source of UV-C radiation, and where each orifice of each cell (156a-d) has a closure system. The disinfection unit also comprises a control unit which controls the turning on and off of each source of UV-C radiation and the passage of each closure system from an open position to a closed position, ensuring the segmentation of a volume of gas into a plurality of segments treated individually in order to ensure an exposure time that is sufficient to ensure complete disinfection.

Financial information

1ventive does not intend to directly use this invention, so we are open to a technology transfer by assigning all the Intellectual Property rights : granted patent FR3115697B1 and its abroad extensions (contact: Link).

Patent publications:

WO 2022258531

FR 3115697

Asking price:

Make an offer
